Forklift Starters

Forklift Starters - A starter motors today is typically a permanent-magnet composition or a series-parallel wound direct current electrical motor with a starter solenoid mounted on it. When current from the starting battery is applied to the solenoid, mainly through a key-operated switch, the solenoid engages a lever which pushes out the drive pinion which is situated on the driveshaft and meshes the pinion using the starter ring gear that is seen on the flywheel of the engine.

The solenoid closes the high-current contacts for the starter motor, that starts to turn. After the engine starts, the key operated switch is opened and a spring in the solenoid assembly pulls the pinion gear away from the ring gear. This action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by means of an overrunning clutch. This allows the pinion to transmit drive in just a single direction. Drive is transmitted in this method via the pinion to the flywheel ring gear. The pinion continuous to be engaged, like for example as the driver fails to release the key as soon as the engine starts or if the solenoid remains engaged since there is a short. This actually causes the pinion to spin independently of its driveshaft.

The actions mentioned above will prevent the engine from driving the starter. This vital step prevents the starter from spinning so fast that it can fly apart. Unless modifications were made, the sprag clutch arrangement would stop making use of the starter as a generator if it was made use of in the hybrid scheme mentioned earlier. Normally a standard starter motor is intended for intermittent utilization that will stop it being used as a generator.

Thus, the electrical parts are intended to be able to function for approximately under 30 seconds to be able to prevent overheating. The overheating results from too slow dissipation of heat due to ohmic losses. The electrical components are intended to save cost and weight. This is actually the reason nearly all owner's handbooks for automobiles recommend the operator to pause for at least 10 seconds right after each ten or fifteen seconds of cranking the engine, whenever trying to start an engine that does not turn over at once.

During the early 1960s, this overrunning-clutch pinion arrangement was phased onto the market. Prior to that time, a Bendix drive was utilized. The Bendix system operates by placing the starter drive pinion on a helically cut driveshaft. When the starter motor begins spinning, the inertia of the drive pinion assembly allows it to ride forward on the helix, therefore engaging with the ring gear. As soon as the engine starts, the backdrive caused from the ring gear enables the pinion to surpass the rotating speed of the starter. At this moment, the drive pinion is forced back down the helical shaft and therefore out of mesh with the ring gear.

During the 1930s, an intermediate development between the Bendix drive was made. The overrunning-clutch design which was made and introduced during the 1960s was the Bendix Folo-Thru drive. The Folo-Thru drive consists of a latching mechanism together with a set of flyweights within the body of the drive unit. This was an enhancement since the typical Bendix drive used in order to disengage from the ring once the engine fired, even though it did not stay running.

The drive unit if force forward by inertia on the helical shaft once the starter motor is engaged and starts turning. After that the starter motor becomes latched into the engaged position. As soon as the drive unit is spun at a speed higher than what is achieved by the starter motor itself, for instance it is backdriven by the running engine, and afterward the flyweights pull outward in a radial manner. This releases the latch and enables the overdriven drive unit to become spun out of engagement, thus unwanted starter disengagement could be prevented prior to a successful engine start.
